Math (Sum, Average, Differential) Modules

  • 6 Year Warranty on API Modules
  • LoopTracker® I/O LEDs
  • Hot-Swappable Plug-In Design
  • Zero and Span Output Calibration
  • Push to Test Output
  • Full I/O/Power Isolation



Click on PDF links below
for product information
Links
Product brochure
Options & accessories
Regulatory compliance

Reference Info
Ground Loops
RFI/EMI
LoopTracker and Output Test
Sink vs Source

Applications
Phase separator water level control
Milling machine feed
How to select your product
  • Open pdf datasheet for your model
  • Select model, range, units, options, accessories
  • Contact us if you need assistance
Need a quote?
Ready to order?
Other ways to order
Model Input/Output Features Product

DC to DC Signal Conditioners
Math Functions


Factory Configured

APD 4400 thru APD 4440  from $559
APD 44xx custom math  from $599

Open Datasheet
Download Datasheet

APD 4400: (A+B+C+D)/4
APD 4401: (A+B+C)/3
APD 4402: (A+B)/2
APD 4403: (A+B+C–D)/3
APD 4404: (A+B–C–D)/2
APD 4405:  A–B–C–D
APD 4406: (A+B–C)/2
APD 4407:  A–B–C
APD 4408:  A–B
APD 4410: A x B
APD 4420: A / B
APD 4430: Input or output squared
APD 4440: Square root of input or output
APD 44xx: Custom math or linearization  from $599
Specify input ranges
Factory configured
Input negative is common
Voltage: 0-50 mVDC to 0-10 VDC
Bipolar voltage: ±25 mVDC to ±10 VDC
Current: 0-1 mADC to 0-20 mADC
Bipolar current: ±0.5 mADC to ±20 mADC

Specify output range
Factory configured
0-1 V to ±10 V
0-2 mA to 0-20 mA, 4-20 mA
  • Output LoopTracker LED
  • Output test button
  • I/O/power isolation
  • Inputs share common ground
  • Hot-swappable design
  • 85-265 VAC, 60-300 VDC power
  • D option for 9-30VDC/10-32VAC power
  • For orders of 5 or more, call us for lead times
APD 44HL New!UL approved
APD 44xx Math Module series

DC to DC Signal Conditioners
High/Low Select Functions


APD44Hx and APD44Lx series  from $559

Open Datasheet
Download Datasheet

APD 44H2: High select from 2 inputs
APD 44H3: High select from 3 inputs
APD 44H4: High select from 4 inputs
APD 44L2: Low select from 2 inputs
APD 44L3: Low select from 3 inputs
APD 44L4: Low select from 4 inputs
Specify input ranges
Factory configured
Input negative is common
Voltage: 0-50 mVDC to 0-10 VDC
Bipolar voltage: ±25 mVDC to ±10 VDC
Current: 0-1 mADC to 0-20 mADC
Bipolar current: ±0.5 mADC to ±20 mADC

Specify output range
Factory configured
0-1 V to ±10 V
0-2 mA to 0-20 mA, 4-20 mA
  • Output LoopTracker LED
  • Output test button
  • I/O/power isolation
  • Inputs share common ground
  • Hot-swappable design
  • 85-265 VAC, 60-300 VDC power
  • D option for 9-30VDC/10-32VAC power
  • For orders of 5 or more, call us for lead times
APD 44HL New!UL approved
APD 44xx Hi/Lo Select series

4 Digit 4-20 mA Loop Powered Display


Field Rangeable


S315  $150 *stock item*
S315-IP66  $310

Open Datasheet
Download Datasheet

Open Installation Manual
Download Installation Manual

Click to see ALL Seneca products

Loop Powered Display
Input: 4-20 mA
Display: 4 digit red LED

  • 1/8 DIN panel mount or IP66 housing
  • Scaleable 4 digit display
